GTH-844

Genie GTH-844 telehandler

The Genie® GTH-844 telehandler offers excellent lift capacity, making it an ideal machine for loading/unloading and moving/placing materials, as well as cleanup, on a variety of jobsites. Choose from an industry-leading 74-hp Tier 4 final Deutz 3.6L engine, a 99-hp Tier 4 final Deutz 3.6L diesel engine, as well as a 99-hp Tier 4 final Perkins diesel engine.

Overview

  • Right-side mount engine provides enhanced visibility
  • Proportional frame-leveling chassis to pick up or place loads on up to 10˚ side slopes and multi-function proportional joystick control for fast, precise load positioning
  • Low-end torque, four-wheel drive and four-wheel steering for hills and rough terrain
  • Standard features include the Quick-Attach system, low-profile tires, fenders (set of 4) and lift shackle at boom tip



Specification Value
Max Lift Capacity 8,000 lb | 3,629 kg
Max Lift Height 43ft 10in | 13.36 m
Max Forward Reach 28ft 2in | 8.59 m
Capacity at Max Height 6,000 lb | 2,722 kg
Capacity at Max Reach 2,000 lbs | 907 kg

Cab Configuration

  • Front and top glass
  • Fully enclosed cab:  full glass, heater, defroster, wipers, washer and split door
  • Fully enclosed cab with air conditioner:  full glass, heater, defroster, wipers, washer and split door

Tire Options

  • Foam-filled rough terrain tires
  • Solid rough terrain tires

Carriage/Attachment Options

  • 48 in. manual Quick-Attach™ carriage
  • 60 in. QA carriage
  • 72 in. QA carriage
  • 48 in. QA side tilt (rotating) carriage
  • 60 in. QA side tilt (rotating) carriage
  • 72 in. QA swing carriage (45 deg L/R)

Fork Options

  • 48 in. pallet forks (2 x 4 x 48 in.)
  • Set of two 60 in. pallet forks,  2 x 4 x 60 in.
  • Set of two 72 in. pallet forks, 2 x 4 x 72 in.
  • Set of two 60 in. lumber forks, 1.75 x 7 x 60 in.
  • Set of six 48 in. cubing tines,  2 x 2 x 48 in.

Accessories

  • Electric block heater
  • Dual joystick control
  • Fire extinguisher
  • Flashing beacon
  • Work lights: High output LED cab, boom, rear
  • Road and Work lights: Work lights and front turn/headlights, rear stop/turn/tail
  • Rear proximity alarm
  • Rear proximity alarm ready
Load chart - Genie GTH-844 telehandler
