GS-3246 E-Drive

Slab Scissor Lifts

Genie GS-2046 scissor lift

Compact dimensions and zero inside turning radius make the Genie® GS™-3246 E-Drive slab scissor lift ideal for indoor and outdoor construction, maintenance, and installation tasks on level ground and in tight spaces. Boasting the state-of-the-art Genie AC electric E-Drive system, it offers unmatched efficiency and runtime when a significant amount of driving is required.

Overview

  • Powerful AC electric drive motors for unmatched driving performance and industry-leading runtime per battery charge
  • Quiet, zero-emission electric operation
  • Easy to maneuver in tight spaces and to drive through standard double doors
  • 25% gradeability with 14° breakover angle to easily get up slopes and loading ramps
  • Large platform workspace with 36 in (0.91 m)  roll-out platform extension
  • Swing out components trays for easy access
  • User-friendly Smart Link™ dual-zone controls for indoor and outdoor use
Specification Value
Max Working Height 38 ft | 11.75 m
Capacity 700 lb | 318 kg
Machine Width 3 ft 10 in | 1.16 m
Machine Length 8 ft | 2.44 m
Weight 5,211 lb | 2,364 kg

Chassis Options

  • AGM maintenance-free batteries
  • Automotive-style horn
  • Biodegradable hydraulic oil
  • Biodegradable hydraulic oil(for GS-3232, GS-3246)
  • Power inverter, 800W,  24V DC,  120V AC, 60 Hz

Certification Options

  • EE Certification

Platform Options

  • Air line to platform:  ? in. inner diameter
