S-85 XC

Telescopic Boom Lift

Genie® telescopic S®-85 XC™ boom lift updates the brand’s popular earlier telescopic unit. This Genie Xtra Capacity™ model offers a dual lift capacity to perform a wider range of heavier lift tasks on construction and industrial jobsites, with innovative features to help increase productivity and efficiency.

Overview

• Full-time active oscillating axle and full-time positive traction for superior terrain ability
• Chassis tilt sensor technology  maximizes access to hard-to-reach work areas
• 1.52 m (5 ft) robust articulating jib
• Dual lifting capacity of 300 kg (660 lb) and 454 kg (1,000 lb) to lift increased loads and up to 3 operators
• Automatic envelope control technology for a smooth operating envelope
• Zero-load field calibration and onboard diagnostics maximize serviceability

Specification Value
Max Working Height 91 ft | 27.91 m
Max Horizontal Reach 74 ft 6 in | 22.71 m
Below Ground Reach 8 ft 8 in | 2.64 m
Platform Capacity 660 lb Unrestricted, 1000 lb Restricted | 300 kg Unrestricted, 454 kg Restricted
Machine Width and Length 8 ft 2 in, 40 ft 7 in | 2.49 m, 12.37 m
  • S-85 XC Product Specifications 2024
  • To view earlier versions of this specification sheet, please click here and look up for your machine Operator Manual by serial number.
    The relevant specification data will be on the last page.
