SX-150

Telescopic Boom Lift

The Genie^® SX™-150 telescopic boom offers uncompromising productivity and industry-leading capacity through the full working envelope. This Genie boom is designed to perform in even the most extreme construction, maintenance, telecommunications, gas and oil, chemical maintenance, and large utility applications.

Overview

Easily position workers and gear with a 10-ft (3.05 m) rotating jib
Designed to be productive, reliable and easy to transport
Features a working envelope ideal for the most extreme access jobs with a vertical reach of 152 ft (46.33 m) and a horizontal reach of 80 ft (24.4 m)
Genie XChassis™ extends and retracts to provide stability on the job and a narrow profile for transport

Get a Quote Order Parts Manuals Sign Up

Specification	Value
Max Working Height	157 ft \| 48.02 m
Max Horizontal Reach	80 ft \| 24.38 m
Below Ground Reach	2 ft \| 0.61 m
Platform Capacity	750 lb \| 340 kg
Machine Width and Length	12 ft 11 in / 46 ft 9 in \| 3.94 m / 14.24 m

SX-150 Product Specifications 2020

Engine Options

Diesel intake air pre-cleaner
Cold weather recirc kit: 5W-40 Synthetic engine oil, oil pan heater, battery heater, platform manifold recirculation, and hydraulic tank heater

Lift/Turntable Options

Hostile environment kit: cylinder bellows, boom wiper seals, platform control box cover, second engine oil filter
Specialty hydraulic oil (225 gal - cold weather, fire resistant, or biodegradable)

Platforms

8 ft. tri entry platform with ½ height mesh inserts and side swing gate

Platform Options

Air line to platform
Light package: 2 platform mounted work lights
Lockable platform control box cover
Thumb rocker steering
Welder - Select Lincoln or Miller
Anemometer
Traveling fall arrest anchor system: requires 8ft platform

Generator Options

AC Generator, 12kW, 208V/110V/60Hz

Range of motion - Genie SX-150 telescopic boom lift

View SX-150_Alt4 Image

View SX-150_Alt2 Image

View SX-150_Alt1 Image

View SX-150_Alt3 Image

View SX-150_Alt6 Image

View SX-150_Alt5 Image

Genie Fall Arrest Bar [ANSI]

X-Chassis

Envelope Control

Genie Lift Guard Contact Alarm
